Stainless Steel Welded Tube Stockist, Stainless Steel 316 Welded Tube Trader, Stainless Steel 316 Welded Tube Exporter, Stainless Steel Welded Tube Supplier & Stockist in India
Shree Chamunda Steels LTD is a highly recommended Stainless Steel Welded Tube Manufacturer, which is known to supply high-quality Stainless Steel Welded Tube with high resistance and good performance in harsh industrial conditions. We are also a Stainless Steel Welded Tube Trader that can be trusted and supply a variety of Stainless Steel Welded Tube. Our Stainless Steel Welded Tube comes in OD of 10.30mm to 254mm, depending on the requirement, with the standard lengths of 20ft and customization depending on customer need. These tubes are manufactured with exact chemical compositions that supply strength, durability, and uniform quality levels that can be used in the industry over a long duration.
Stainless Steel Welded Tube Dealer, Stainless Steel 304 Welded Tube Price, Stainless Steel 310 Welded Tube Distributor, 316H Stainless Steel Welded Tube Stockist, Stainless Steel Welded Tube Supplier in India
Specification Of Stainless Steel Welded Tube
| Stainless Steel ERW Tube | Specification |
| Standards | ASTM A 312/ ASME SA 312/ A790/ SA790/ EN10216-5 |
| Grades | 304L, 304, 309S, 316, 316L, 310S, 310 |
| NB Size Pipe | ½” to 24” NB |
| Schedule | Sch 5s, Sch 10s, Sch 20s, Sch 40s, Sch 80s, Sch XXS |
| OD Size Pipe | 10.30mm to 254mm as per requirement |
| Thickness | Up to 10mm |
| Types | As Welded, EFW, ERW |
| Manufacturing Shapes | Round, Square, Rectangle, Box Section |
| SS ERW Pipe Surface Finish | Cold Finish, Matt Finish, Bright, Polished, Annealing, Pickling, Mirror Finish, or as per requirements |
| Length | 20ft (Standard) & As per Customer Requirement |
Grades Of Stainless Steel Welded Tube Available
Stainless Steel 316 Welded Tube
Stainless Steel 310 Welded Tube
Stainless Steel 304 Welded Tube
316H Stainless Steel Welded Tube
347 Stainless Steel Welded Tube
904L Stainless Steel Welded Tube
321 Stainless Steel Welded Tube
Engineered for performance, built for industry — Shree Chamunda Steels LTD, Stainless Steel Welded Tube Manufacturer in India.
Shree Chamunda Steels LTD
Applications Of Stainless Steel Welded Tube
Paper & Pulp Industries
Automobile Industries
Oil & Gass Industries
Chemical Industries
Medical Industries
Aerospace Industries
Manufacturing Process Of Stainless Steel Welded Tube
Schedule Chart Of Stainless Steel Welded Tube
| Nominal Broe | Outside Diameter | Sch 5s | Sch 10s | Sch 40s | Sch 80s | Sch 160s | Sch XXS | |||||||
| mm | INCH | mm | Wt mm | Weight (Kg/mt) | Wt mm |
Weight (Kg/mt) | Wt mm |
Weight (Kg/mt) | Wt mm |
Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | Wt mm |
Weight (Kg/mt) |
| 3 | 1/8 | 10.3 | 1.24 | 0.276 | 1.24 | 028 | 1.73 | 0.37 | 2.41 | 0.47 | - | - | - | - |
| 6 | 1/4 | 13.7 | 1.24 | 0.390 | 1.65 | 049 | 2.24 | 0.631 | 3.02 | .0.80 | - | - | - | - |
| 10 | 3/8 | 17.1 | 1.24 | 0.490 | 1.65 | 0.63 | 2.31 | 0.845 | 3.20 | 1.10 | - | - | - | - |
| 15 | 1/2 | 21.3 | 1.65 | 0.800 | 2.11 | 1.00 | 2.77 | 1.27 | 3.75 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
| 20 | 3/4 | 26.7 | 1.65 | 1.03 | 2.11 | 1.28 | 2.87 | 1.68 | 3.91 | 2.20 | 5.54 | 2.89 | 7.82 | 3.63 |
| 25 | 1 | 33.4 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.20 | 6.35 | 4.24 | 9.09 | 5.45 |
| 32 | 1.1/4 | 42.2 | 1.65 | 1.65 | 2.77 | 2.70 | 3.56 | 3.38 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
| 40 | 1.1/2 | 48.3 | 1.65 | 1.91 | 2.77 | 3.11 | 3.68 | 4.05 | 5.08 | 5.41 | 7.14 | 7.25 | 10.16 | 9.54 |
| 50 | 2 | 60.3 | 1.65 | 2.40 | 2.77 | 3.93 | 3.91 | 5.44 | 5.54 | 7.48 | 8.74 | 11.1 | 11.07 | 13.44 |
| 65 | 2.1/2 | 73.0 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.63 | 7.01 | 11.4 | 9.53 | 14.9 | 14.2 | 20.39 |
| 80 | 3 | 88.9 | 2.11 | 4.51 | 3.05 | 6.45 | 5.49 | 11.30 | 7.62 | 15.2 | 11.1 | 21.3 | 15.24 | 27.65 |
| 100 | 4 | 114.3 | 2.11 | 5.84 | 3.05 | 8.36 | 6.02 | 16.07 | 8.56 | 22.3 | 13.49 | 33.54 | 17.12 | 41.03 |
| 125 | 5 | 141.3 | 2.77 | 9.47 | 3.40 | 11.57 | 6.55 | 21.80 | 9.53 | 31.97 | 15.88 | 49.11 | 19.05 | 57.43 |
| 150 | 6 | 168.3 | 2.77 | 11.32 | 3.40 | 13.84 | 7.11 | 28.30 | 10.97 | 42.7 | 18.2 | 67.56 | 21.95 | 79.22 |
| 200 | 8 | 219.1 | 2.77 | 14.79 | 3.76 | 19.96 | 8.18 | 42.60 | 12.7 | 64.6 | 23.0 | 111.2 | 22.23 | 107.8 |
| 250 | 10 | 273.1 | 3.40 | 22.74 | 4.19 | 28.00 | 9.27 | 60.50 | 15.1 | 96.0 | 28.6 | 173.0 | 25.40 | 155.15 |
| 300 | 12 | 323.9 | 3.96 | 31.50 | 4.57 | 36.00 | 10.30 | 79.80 | 17.5 | 132.0 | 33.32 | 238.76 | 25.40 | 186.97 |
| 350 | 14 | 355.6 | 3.96 | 34.36 | 4.78 | 41.3 | 11.13 | 94.59 | 19.05 | 158.08 | 35.71 | 281.70 | - | - |
| 400 | 16 | 406.4 | 4.19 | 41.56 | 6.35 | 62.64 | 12.7 | 123.30 | 21.41 | 203.33 | 40.46 | 365.11 | - | - |
| 450 | 18 | 457.2 | 4.19 | 46.80 | 4.78 | 53.42 | 14.27 | 155.80 | 23.8 | 254.36 | 45.71 | 466.40 | - | - |
| 500 | 20 | 508.0 | 4.78 | 59.25 | 5.54 | 68.71 | 15.09 | 183.42 | 26.19 | 311.2 | 49.99 | 564.68 | - | - |
| 600 | 24 | 609.6 | 5.54 | 82.47 | 6.35 | 94.45 | 17.48 | 255.41 | 30.96 | 442.08 | 59.54 | 808.22 | - | - |
Chemical Properties Of Stainless Steel Welded Tube
| A312 GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
| TP304 | S3040 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-13.0 | ||||
| TP304L | S30409 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304N | S30451 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-18.0 | 0.10-0.16 | |||
| TP304LN | S30453 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-12.0 | 0.10-0.16 | |||
| TP309S | S30908 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-15.0 | 0.75 | |||
| TP309H | S30909 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-15.0 | ||||
| TP309Cb | S30940 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-16.0 | 0.75 | 10xC min 1.10 max |
||
| TP309HCb | S30941 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 22.0-24.0 | 12.0-16.0 | 0.75 | 10xC min 1.10 max |
||
| TP310S | S3108 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | |||
| TP310H | S3109 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | ||||
| TP310Cb | S31040 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | 10xC min 1.10 max |
||
| TP310HCb | S31041 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 24.0-26.0 | 19.0-22.0 | 0.75 | 10xC min 1.10 max |
||
| TP316 | S3160 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |||
| TP316H | S31609 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316Ti | S31635 | 0.08 | 2.0 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 5x (C-N) -0.70 |
0.10 | |
| TP316N | S31651 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.10-0.16 | ||
| TP316LN | S31653 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | 0.10-0.16 | ||
| TP317 | S3170 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 10.0-14.0 | 3.0-4.0 | |||
| TP317L | S31703 | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 | |||
| TP321 | S3210 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-12.0 | 0.10 | |||
| TP321H | S32109 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-12.0 | 0.10 | |||
| TP347 | S3470 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
| TP347H | S34709 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
| TP347LN | S34751 | 0.05-0.02 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | 0.20- 50.0 |
0.06-0.10 | ||
| TP348 | S3480 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 | ||||
| TP348H | S34809 | 0.04-0.10 | 2.0 | 0.045 | 0.030 | 1.0 | 17.0-19.0 | 9.0-13.0 |
